2-wire IP network switch 6 Terminals 48VDC Akuvox NS-2

2-wire IP Network Switch, 6 Terminals, 48VDC; NS-2 is Akuvox  2-wire IP network switch that provides a convenient way to upgrade analog intercom systems, with no need for rewiring. Its super long transmission distance & good compatibility with existing lines makes it fit for most old buildings.

Published On: 05/17/2022Categories: , SKU: NS-2

2-wire IP network switch 6 Terminals 48VDC Akuvox NS-2 Features:

  • Support network and power supply for R20A-2 or C313W-2 through 2-wire cable;
  • Support multi-level cascade through 2-wire cable;
  • Connects up to 6 pcs of Akuvox 2-wire IP intercom devices;
  • Super long transmission distance via 2-wire cable;
  • Powered by 48VDC or 24VDC power supply unit;
  • Rail mounting installation

Physical & Power:

  • Communication: TCP/IP
  • RJ45 port: 1 x RJ45 port, 10/100Mbps adapter
  • 2-wire ports: 6 pair
  • Working voltage: 48V or 24V
  • Status Indicator: 4
  • Installation: Rail mounting
  • Working temperature: -20℃~+50℃
  • Storage temperature: -20℃~+70℃
  • Working humidity: 10%~90%
  • Dimension: 161 x 90 x 65 (mm)

2-wire IP network switch 6 Terminals 48VDC Akuvox NS-2 is best for Old building retrofit

NS-2 Long Data Transmission Distance provides a convenient way to upgrade analog intercom systems, with no need for rewiring. Its super long transmission distance & good compatibility with existing lines makes it fit for most old buildings.
