2MP 30x Starlight IR PTZ Network Camera | PDN6AF230HN-EI
Availability: Out of stock
SKU:
PDN6AF230HN-EI
1/2.8" 2MP 45x Starlight Laser PTZ Network Camera, Smart H.265+, 3.95-177.7mm Motorized, 60fps@2MP, Auto-Tracking, Micro-SD Slot, Built-in 7/2 Alarm in/out, Laser 1804' IR, IP67, AC24V, Hi-PoE, UL Listed
Features
- 1/1.9” 2Megapixel CMOS
- Powerful 30x optical zoom
- Starlight technology
- Max. 25/30fps@1080P, 25/30/50/60fps@720P
- Support Hi-PoE
- IR distance up to 200m
- IP67 , IK10
Download
| Image Sensor | 1/1.9" CMOS | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Image Size | 1920(H) x 1080(V), 2 Megapixels | ||||||||||||
| RAM/ROM | 1024M/64M | ||||||||||||
| Electronic Shutter | 1/1s~1/30,000s | ||||||||||||
| Minimum Illumination | Color: 0.002Lux@F1.5; B/W: 0.0002Lux@F1.5; 0Lux@F1.5 (IR on) | ||||||||||||
| S/N Ratio | > 56dB | ||||||||||||
| Video Output | N/A | ||||||||||||
| Day / Night | Auto(ICR) / Color / B/W | ||||||||||||
| BLC Mode | BLC / HLC / WDR(120dB) | ||||||||||||
| White Balance | Auto, ATW, Indoor, Outdoor, Manual | ||||||||||||
| Gain Control | Auto / Manual | ||||||||||||
| Digital Noise Reduction | Ultra DNR (2D/3D) | ||||||||||||
| Privacy Masking | Up to 24 areas | ||||||||||||
| Optical Zoom | 30x | ||||||||||||
| Digital Zoom | 16x | ||||||||||||
| Electronic Image Stabilization (EIS) | Support | ||||||||||||
| Defog | Support | ||||||||||||
| Wide Dynamic Range | 120dB | ||||||||||||
| DORI Distance |
|
||||||||||||
| Focal Length | 6mm~180mm | ||||||||||||
| Max. Aperture | F1.5~ F4.3 | ||||||||||||
| Focus Control | Auto / Manual | ||||||||||||
| Angle of View | F1.5~ F4.3 | ||||||||||||
| Close Focus Distance | 100mm~ 1000mm | ||||||||||||
| Laser Light Control | NA | ||||||||||||
| IR LEDs | 10 | ||||||||||||
| IR Distance | Distance up to 200m (656ft) | ||||||||||||
| IR On/Off Control | Auto/Manual | ||||||||||||
| Angle of Laser Light | NA | ||||||||||||
| Pan Range | Pan: 0° ~ 360° endless; auto flip 180° | ||||||||||||
| Pan Speed | Pan: 0.1° ~200° /s | ||||||||||||
| Tilt Range | Tilt: -20° ~ 90° | ||||||||||||
| Tilt Speed | Tilt: 0.1° ~120° /s | ||||||||||||
| Number of Preset | 300 | ||||||||||||
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan ,Auto Scan | ||||||||||||
| Speed Setup | Human-oriented focal Length/ speed adaptation | ||||||||||||
| Power Up Action | Auto restore to previous PTZ and lens status after power failure | ||||||||||||
| Idle Motion | Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period | ||||||||||||
| Time Task | Auto activation of Preset / Pan / Scan / Tour / Pattern by preset-time | ||||||||||||
| Video Compression | H.264 / MJPEG | ||||||||||||
| Video Resolution | 1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240) | ||||||||||||
| Video Frame Rate | Main stream: 1080P(1~25/30fps), 720P(1~50/60fps) |
||||||||||||
| Video Bitrate | H.264: 448K~8192Kbps, MJPEG: 4096K~20480Kbps | ||||||||||||
| Smart Tracking | Tracking the specified target | ||||||||||||
| AI Perimeter Protection | Tripwire, Intrusion, Abandoned/Missing | ||||||||||||
| Tracking Trigger Mode | N/A | ||||||||||||
| Tracking Trigger Event | Motion detection, Video tampering , Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly | ||||||||||||
| Audio Compression | G.711a/G.711Mu/AAC/G.722 / G.726/G.729/MPEG2-L2 | ||||||||||||
| Audio In | 1CH | ||||||||||||
| Audio Out | 1CH | ||||||||||||
| IPC Alarm | Yes | ||||||||||||
| Alarm In | 7CH | ||||||||||||
| Alarm Out | 2CH | ||||||||||||
| Ethernet | RJ-45 (10XBase-T/100Base-TX) | ||||||||||||
| Network Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x | ||||||||||||
| Network Interoperability | ONVIF Profile S&G, API | ||||||||||||
| Streaming Method | Unicast / Multicast | ||||||||||||
| Network Max. Users | 20 users | ||||||||||||
| Storage | Local PC for instant recording, Micro SD card 128GB | ||||||||||||
| Storage Card | Micro SD card 128GB | ||||||||||||
| Web Viewer | IE, Chrome, Firefox, Safari | ||||||||||||
| Management Software | Smart PSS, DSS, DMSS | ||||||||||||
| Mobile | iPhone, Android | ||||||||||||
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 UL: UL60950-1+CAN/CSA C22.2,No.60950-1 |
||||||||||||
| RS485 | 1 | ||||||||||||
| Power Supply | AC24V/3A(±25%), PoE+(802.3at) | ||||||||||||
| Power Consumption | 24W, 38W (IR on) | ||||||||||||
| Operating Temperature | -40°C ~ 60°C (-40°F ~ +140°F) / Less than 95% RH | ||||||||||||
| Ingress Protection | IP67,IK10 | ||||||||||||
| Dimensions | Φ9.4(in)×15.0(in) | ||||||||||||
| Weight | Net Weight 6.75kg(14.88lb) Gross Weight 10.5kg(23.15lb) | ||||||||||||
