3MP H.265 Fixed Lens Bullet Network Camera | HNC3130S-IR/36-S2

Availability: In stock

1/3" 3MP Fixed Lens Bullet, 3.6mm Lens, 20fps@3MP, 30fps@1080p, IP67, 98' IR, PoE, Alps Chipset, UL Listed


  • 1/3” 3 Megapixel progressive scan CMOS
  • H.264 & MJPEG dual-stream encoding
  • Max 20fps@3M(2048× 1536) & 25/30fps@1080P(1920× 1080)
  • DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
  • Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
  • 3.6mm fixed lens
  • Max. IR LEDs Length 100ft.
  • IP67, PoE


More Information
Image Sensor 1/3” 3Megapixel progresive CMOS
Image Size 2048(H) 1536(V)
Electronic Shutter Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination

0. 1Lux/F2.0(Color), 0Lux/F2.0(IR on)

S/N Ratio > 50dB
IR LEDs 18
Smart IR Support
IR Distance Distance up to 30m(98ft)
IR On/Off Control Auto/Manual
Focal Length 3.6mm
Angle of View H:77°, V:41°
Max. Aperture F2.0
Optical Zoom N/A
Close Focus Distance N/A
Pan / Tilt / Rotation Pan/Tilt Range Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
Video Compression H.264+/H.264
Streaming Capability 2 Streams
Video Resolution

3M(2048×1536)(2304×1296)/ 1080P(1920×1080)/720P(1280×720)/ D1(704×576/704×480)/ CIF(352×288/352×240)

Video Frame Rate

Main Stream: 3M(1 ~ 20fps)/2M (1 ~ 25/30fps)
Sub Stream: D1/CIF(1 ~ 25/30fps)

Video Bitrate

H264:24K ~ 8192Kbps

Day / Night Auto(ICR) / Color / B/W
White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control Auto/Manual
Digital Noise Reduction 3D DNR
Motion Detection Off / On (4 Zone, Rectangle)
Region of Interest Off / On (4 Zone)
Electronic Image Stabilization (EIS) Support
Defog Support
Digital Zoom 16x
Flip 0°/90°/180°/270°
Mirror Off / On
Privacy Masking Off / On (4 Area, Rectangle)
Audio Compression N/A
IPC Alarm N/A
Alarm In N/A
Alarm Out N/A
General Function Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
AI Perimeter Protection Tripwire, Intrusion
Advanced AI Functions Motion detection, Video tampering, Scene changing, Network disconnection, Ip address conflict, Illegal access, Storage anomaly
Ethernet RJ-45 (100/1000Base-T)
Network Interoperability ONVIF, PSIA, CGI
Streaming Method Unicast / Multicast
Network Max. Users 10 Users / 20 Users
Storage NAS Local PC for instant recording
Storage Card N/A
Web Viewer IE, Chrome, Firefox, Safari
Management Software Smart PSS, DSS, Easy4ip
Mobile iPhone, Android
Video Output N/A
Certifications CE (EN 60950:2000)
FCC: FCC Part 15 Subpart B

Audio Interface N/A
RS485 N/A
Power Supply DC12V PoE (802.3af)(Class 0)
Power Consumption <7.5W
Operating Temperature -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Storage Temperature -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection IP67
Dimensions Φ70mm×164.7mm(2.76''x6.49'')
Weight Net Weight 0.38Kg(0.84lb) Gross Weight 0.44Kg(0.97lb)
