3MP H.265 Bullet Network Fixed Security Camera HNC3130S-IR/36-S2

Availability: Out of stock
SKU:
HNC3130S-IR/36-S2
1/3" 3MP Bullet, 3.6mm Fixed Lens, 20fps@3MP, 30fps@1080p, IP67, 98' IR, PoE, Alps Chipset, UL Listed professional surveillance products.
  • Remote viewing from your mobile with ENS Security. you can quickly and easily view your security system remotely through your smartphone, tablet, or PC. free download app and no monthly fees.
  • Features
  • 1/3” 3 Megapixel progressive scan CMOS
  • H.264 & MJPEG dual-stream encoding
  • Max 20fps@3M(2048× 1536) & 25/30fps@1080P(1920× 1080)
  • DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
  • Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
  • 3.6mm fixed lens
  • Max. IR LEDs Length 100ft.
  • IP67, PoE
  • This IP Security Camera works with: Diamond Networking Video Recorder(NVR)

    More Information
    Image Sensor 1/3” 3Megapixel progresive CMOS
    Image Size 2048(H) 1536(V)
    RAM/ROM 256MB/16MB
    Electronic Shutter Auto/Manual, 1/3(4)~1/100000s
    Minimum Illumination

    0. 1Lux/F2.0(Color), 0Lux/F2.0(IR on)

    S/N Ratio > 50dB
    IR LEDs 18
    Smart IR Support
    IR Distance Distance up to 30m(98ft)
    IR On/Off Control Auto/Manual
    Focal Length 3.6mm
    Angle of View H:77°, V:41°
    Max. Aperture F2.0
    Optical Zoom N/A
    Close Focus Distance N/A
    Pan / Tilt / Rotation Pan/Tilt Range Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
    Video Compression H.264+/H.264
    Streaming Capability 2 Streams
    Video Resolution

    3M(2048×1536)(2304×1296)/ 1080P(1920×1080)/720P(1280×720)/ D1(704×576/704×480)/ CIF(352×288/352×240)

    Video Frame Rate

    Main Stream: 3M(1 ~ 20fps)/2M (1 ~ 25/30fps)
    Sub Stream: D1/CIF(1 ~ 25/30fps)

    Video Bitrate

    H264:24K ~ 8192Kbps

    Day / Night Auto(ICR) / Color / B/W
    BLC Mode BLC / HLC / DWDR
    White Balance Auto/Natural/Street Lamp/Outdoor/Manual
    Gain Control Auto/Manual
    Digital Noise Reduction 3D DNR
    Motion Detection Off / On (4 Zone, Rectangle)
    Region of Interest Off / On (4 Zone)
    Electronic Image Stabilization (EIS) Support
    Defog Support
    Digital Zoom 16x
    Flip 0°/90°/180°/270°
    Mirror Off / On
    Privacy Masking Off / On (4 Area, Rectangle)
    Audio Compression N/A
    IPC Alarm N/A
    Alarm In N/A
    Alarm Out N/A
    General Function Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
    AI Perimeter Protection Tripwire, Intrusion
    Advanced AI Functions Motion detection, Video tampering, Scene changing, Network disconnection, Ip address conflict, Illegal access, Storage anomaly
    Ethernet RJ-45 (100/1000Base-T)
    Network Protocol HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;
    DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;
    Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP
    Network Interoperability ONVIF, PSIA, CGI
    Streaming Method Unicast / Multicast
    Network Max. Users 10 Users / 20 Users
    Storage NAS Local PC for instant recording
    Storage Card N/A
    Web Viewer IE, Chrome, Firefox, Safari
    Management Software Smart PSS, DSS, Easy4ip
    Mobile iPhone, Android
    Video Output N/A
    Certifications CE (EN 60950:2000)
    UL:UL60950-1
    FCC: FCC Part 15 Subpart B

    Audio Interface N/A
    RS485 N/A
    Power Supply DC12V PoE (802.3af)(Class 0)
    Power Consumption <7.5W
    Operating Temperature -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
    Storage Temperature -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
    Ingress Protection IP67
    Dimensions Φ70mm×164.7mm(2.76''x6.49'')
    Weight Net Weight 0.38Kg(0.84lb) Gross Weight 0.44Kg(0.97lb)
