4MP HDCVI Dome Camera, 2.7-13.5mm Vari-Focal Lens | HCC3340R-IR-VF

Availability: In stock
SKU:
HCC3340R-IR-VF
1/3" 4MP HD-CVI IR Eyeball Camera, 2.7-13.5mm Manual Varifocal Lens, IP67, Analog Switchable (OSD), DC12V, 98' IR, UL Listed
  • Max. 30fps@1080P
  • HD and SD output switchable
  • 2.7-13.5mm vari-focal lens
  • Max. IR length 30m (98ft), Smart IR
  • IP67, DC12V
More Information
Image Sensor 1/3" CMOS
Image Size 2688(H) x 1520(V)
Electronic Shutter PAL: 1/25~1/100,000s; NTSC: 1/30~1/100,000s
Minimum Illumination 0.03Lux/F1.3, 30IRE, 0Lux IR on
S/N Ratio More then 65dB
IR LEDs 20
Smart IR Support
IR Distance 98ft (30m)
IR On/Off Control Auto / Manual
Focal Length 2.7-13.5mm
Angle of View H: 98°~26°
Max. Aperture F1.3
Optical Zoom N/A
Close Focus Distance 200mm (7.87")
DORI Distance
  DORI Definition Distance
Wide Tele
Detec 25px/m (8px/ft) 64m (210ft) 222m (728ft)
Observe 63px/m (19px/ft) 26m (84ft) 89m (291ft)
Recognize 125px/m (38px/ft) 13m (42ft) 44m (146ft)
Identify 250ppm (76px/ft) 6m (21ft) 22m (73ft)
Pan / Tilt / Rotation Pan: 0° ~ 360°; Tilt: 0° ~ 90°; Rotation: 0° ~360°
Video Compression N/A
Video Resolution 2560 x 1440
Video Frame Rate 25/30fps@4MP, 25/30fps@1080P, 25/30fps@720P
Day / Night Auto (ICR) / Manual
BLC Mode BLC / HLC / DWDR
White Balance Auto / Manual
Gain Control AGC
Digital Noise Reduction 2D
Motion Detection N/A
Audio Compression N/A
Video Output 1-channel BNC HDCVI high definition video output & 1-channel BNC CVBS video output (Can switch)
Certifications CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Audio Interface N/A
RS485 N/A
Alarm In N/A
Alarm Out N/A
Power Supply 12V DC ±25%
Power Consumption Max. 4.6W (12V DC, IR on)
Operating Temperature -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH; Start up should be done at above -40°C (-40°F)
Storage Temperature -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
Ingress Protection IP67
Dimensions ⌀119mm x 97.4mm (⌀4.69" x 3.83")
Weight Net weight 0.56kg (1.23lb); Gross weight 0.69kg (1.52lb)
